Sierra SP21020 Touch Switch Panel, 4-Function
Sierra

Sierra SP21020 Touch Switch Panel, 4-Function

Our Item #: VLAN11-SP21020 UPC: 808282382339
Delivery i
3-5 Business Days
1 available
Ship to Store i
Pickup in 2-4 days
1 available
This Item is only available in South Florida
$159.29
  • Panel Cut-Out: 15mm hole
  • Circuit Protection: Built-in Resettable Fuse (PPTC)
  • Switch Ratings: 10A per function at 12VDC
  • Panel Rating: Max Cumulative Amp: 35A
  • Voltage Rating: 11-30VDC
  • Membrane Touch Control Panels designed for the harsh Marine Environment
  • Ultra Compact panel size up to 60% smaller than traditional panels
  • Easy to install; almost no mounting depth required
  • Uses micro-USB cable instead of bulky cables
  • Flexible wiring allows the control relay hub to remote mount up to 1 meter away from the touch panel
  • LED- ON indication
  • 10A Self-resettable fuse for each function
  • Backlit push buttons allow for easy readability in the dark
  • Uses very low standby current
  • Programmable buttons allow each function to be programmed as a latching or momentary circuit
  • Includes a 60 piece assortment of graphic and text labels
  • Faceplate PET membrane touch panel
  • CE Certified; Panel only is IP 67 Rated

    • UPC: 808282382339
    Model Number: SP21020
