SharkBite EB75 Series 23000-0045 Pressure Regulating Valve, 3/4 in Connection, FPT, Iron Body
SHARKBITE

SharkBite EB75 Series 23000-0045 Pressure Regulating Valve, 3/4 in Connection, FPT, Iron Body

Our Item #: VORG3071974 UPC: 697285230002
$37.32 $46.69you save $9.37
The EB75 is a compact, iron-body pressure reducing and regulating valve designed for installations where small size and economy are important. Because of the iron body, this valve is not recommended for use in potable water applications. The EB75 comes factory set at 45 psi but has an adjustment range of 10 to 70 psi. The valve also comes in a low-pressure range of 0-20 psi.
Unit: EA
UPC: 697285230002
Model Number: 23000-0045

  • Inbuilt back-pass check allows water to flow back through the regulator in cases of thermal expansion caused by hot water heating devices
  • Fully pressure-balanced piston automatically reduces and regulates high inlet pressures from a maximum of 300 psi down to 45 psi at standard factory setting

  • Body Material: Iron
  • Connection Size: 3/4
  • Connection Type: FPT
  • Dimensions: 3-49/64 in L x 4-3/8 in H
  • Media: Air Water
  • Operating Pressure: 10 to 70
  • Softgoods material: EPDM/Polysulphone
  • Temperature Rating: 180
  • Trim Material: Iron/Steel
