Features
- Patented commercial-grade clutching motor drive, tested to one million cycles
- Vandal-resistant clutching lever and knob design
- Code control, six-digit programming code required to add and delete user codes
- Warning code sounds after four incorrect codes entered, keypad disabled for 30 s
- Mechanical key override, patent pending
- 19 user code capacity, 10,000 user code combinations
- Easily programmed right at the keypad, no need to remove inside escutcheon
- Reversible lever for left-hand or right-hand doors
- Emergency exit feature, allows for panic-free exit
- Silicone rubber, wear-resistant buttons with LED backlight
More Specifications
- Design: Wave
- Finish: Satin Nickel
- Commercial/Residential: Residential
- Security Grade: 2
- Material: Metal
- Handle Type: Lever
- Interior Handle Type:
- Keypad Included: Yes
- Door Handing:
- Operating System Compatibility:
- Keyway Type: C
- Cylinder Type: 5-Pin Standard Cylinder
- Number of Cylinders: 1
- Latch Type: DeadLatch
- Number of User Codes: 19
- Rekeyable/Resettable:
- Biometric Lock:
- Power Source: Battery
- Battery Life: Up to 1 Year
- Connectivity:
- Lighted Keypad: Yes
- Mounting Type:
- Lever Length:
- Knob Diameter:
- Faceplate Size: 1 x 2-1/4 in
- Strike Type: Full Lip Round Corner
- Strike Size: 1.63 x 2.25 in
- Bolt Type:
- Bolt Throw Size:
- Projection Size: 1/2 in
- Door Thickness: 1-3/8 to 1-3/4 in
- Edge Bore Diameter: 1 in
- Cross Bore Diameter: 2-1/8 in
- Latch Housing Diameter: 7/8 in
- Deadbolt Latch Throw:
- Grip Center to Center:
- Backset Type: Adjustable
- Backset Size: 2-3/8, 2-3/4 in
- Suitable for:
- Resists:
ANSI Specified | CE Certified | UL Listed
