Legrand CR20I Duplex Receptacle, 2 -Pole, 20 A, 125 V, Side Wiring, NEMA: 5-20R, Ivory
Pass & Seymour/Legrand

Legrand CR20I Duplex Receptacle, 2 -Pole, 20 A, 125 V, Side Wiring, NEMA: 5-20R, Ivory

Our Item #: VORG0254003 UPC: 785007042962
Delivery i
3-5 Business Days
310 available
Ship to Store i
Pickup in 2-4 days
30 available
$3.07 $3.85you save $0.78
Pass & Seymour Duplex Receptacle, 125 V, 20 A, 2 Pole, 3 Wires, Side Wiring, 14 to 10 AWG Wire, 5-20R, -40 to 50 deg C Operating, Wall Mounting, Nylon/Thermoplastic, Ivory, Dimensions: 3.281 in H x 1.322 in W x 0.78 in D
Unit: EA
UPC: 785007042962
Model Number: CR20ICC12
Legrand CR20I Duplex Receptacle, 2 -Pole, 20 A, 125 V, Side Wiring, NEMA: 5-20R, Ivory
$3.07$3.85

  • Corrosion-resistant, plated steel strap locked in to face and back body to resist pulling away from face/body assembly
  • 0.032 in thick, brass, triple wipe power contacts for lasting retention
  • Easily accessed break-off, line contact connecting tab for fast, easy split circuit wiring
  • Impact-resistant nylon face and thermoplastic back body
  • Accepts #14 to #10 AWG solid or stranded copper or copper-clad wire
  • Terminal compartments isolated from each other for positive conductor containment
  • Tri-drive terminal and mounting screws
  • Auto-ground clip assures positive ground

  • Color: Ivory
  • Current Rating: 20 A
  • Dimensions: 3.281 in H x 1.322 in W x 0.78 in D
  • Material: Nylon/Thermoplastic
  • Mounting Type: Wall
  • NEMA Configuration: 5-20R
  • Number of Poles: 2
  • Number Of Wires: 3
  • Operating Temperature: -40 to 50 deg C
  • Voltage Rating: 125 V
  • Wire Size: 14 to 10 AWG
  • Wiring Type: Side
